NON PFAS FKM Precompound ,Compatible with EU Regulations Providing Excellent Resistance to Chemical Degradation and Thermal Aging for Extended Service Life

Brand Name: DOWHON
Model Number: DHF/FD
MOQ: 20KGS
Price: 8-12usd/kg
Packaging Details: 20KGS PER CARTON, 500KGS PER PALLET, 12MT IN ONE 20FCL.
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
CHENGDU, CHINA
Certification:
ISO-9001, ISO-14001, IATF16949, ISO-45001.
Carton Weight:
20kg
Usage:
, O RINGS, Etc,
Thickness:
2mm-8mm
Odor:
ODORLESS
Specific Gravity:
1.81
Weather Resistance:
Excellent
Mooney Viscosity Ml:
40
Tensile Strength:
15.6 Mpa
Dimensions:
445*305*145mm
Supply Ability:
600MT PER MONTH
Highlight:

FKM rubber precompound EU compliant

,

non-PFAS FKM chemical resistant

,

FKM precompound thermal aging resistant

Product Description
NON-PFAS FKM Precompound – EU Regulation Compliant
Fluoroelastomer FKM PFAS-FREE compound designed for O-ring applications, providing excellent resistance to chemical degradation and thermal aging for extended service life.
Product Overview
FD-401NFS is a fluoroelastomer precompound containing copolymer of hexafluoropropylene and vinylidene fluoride with curatives. Specifically designed for O-rings, seals, gaskets, and other complex shapes.
Basic Characteristics
Property Value
Fluorine Content 66%
Specific Gravity 1.81
Physical Form Slab
Color Off-white
Solubility Ketones and Esters
Mooney Viscosity ML 1+10@ 121ºC 39
Key Features
  • Excellent mold release
  • Low compression set
  • Increased cure rate
  • Less mold fouling
  • Increased mold flow
Processing Procedures
FD-401NFS can be compounded with internal mixers or two-roll mills using standard fillers and ingredients typical for fluoroelastomer formulations. All dry ingredients should be blended before adding to the rubbery solid. Full cooling should be maintained during compounding, and the compound should be cooled as quickly as possible after mixing.
Packing Information
FD-401NFS is packed with PE film in cartons. Net weight: 20kg per carton.
Safety and Handling
  • Store in well-ventilated place
  • Smoking strictly forbidden in working areas
  • Avoid eye contact
  • Wash thoroughly any contacted skin and clothing after handling
  • Refer to product's Material Safety Data Sheet or consult Dowhon personnel for complete safety guidelines
Typical Properties
Compound Formulation
Component Parts
FD-401NFS 100
MT Black (N990) 30
MgO 3
Ca(OH)2 6
Carnauba Wax 1
Rheological Properties
ALPHA PREMIER MDR, 100 cpm 0.5 Arc 177℃@ 6min
Property Value Test Method
ML, lb.in 1.42 ASTM D6601
MH, lb.in 20.54 ASTM D6601
Ts2, min 1:16 ASTM D6601
T10, min 1:16 ASTM D6601
T90, min 2:29 ASTM D6601
Physical Properties
Press Cure 180℃@5min, Post Cure 230℃@24hour
Property Value Test Method
Tensile Strength, MPa 16.6 ASTM D412
Elongation at Break, % 191 ASTM D412
Hardness, Shore A 74 ASTM D2240
Compression Set % 200℃@70h 16 ASTM D395, method B
Low Temperature Resistance Tr10, ℃ -17 ASTM 1329
