FKM Rubber Precompound designed to meet requirements of extrusion products especially low permeability fuel hose bonding

All Category

Fluorocarbon Rubber

Ms. Cheng

shcheng@dowhon.com

+8613408548504

Contact Now

FKM Rubber Precompound designed to meet requirements of extrusion products especially low permeability fuel hose bonding

Brand Name:	DOWHON
Model Number:	DTR-5925HGV
MOQ:	20KGS
Price:	10-15usd/kg
Packaging Details:	20KGS PER CARTON, 500KGS PER PALLET, 12MT IN ONE 20FCL.
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Chengdu, Sichuan

Certification:

ISO-9001, ISO-14001, IATF16949, ISO-45001.

Fuel Resistance:

Excellent

Oil Resistance:

Excellent

Elongation At Breakage:

Fluorine Content:

69.5%

Elongationatbreak:

150-250%

Appearance:

Solubility:

Ketones And Esters

Heat Resistance:

250°C

Aging Resistance:

Excellent

Width:

As Require

Odor:

ODORLESS

Productname:

FKM Rubber Precompound

Industry:

Automotive Industry For Fuel System

Processingmethod:

Injection Molding, Extrusion

Supply Ability:

300mt per month

Highlight:

FKM rubber precompound extrusion

FKM rubber fuel hose bonding

low permeability FKM rubber

Product Description

FKM Rubber Precompound for Extrusion Products

DTR-5925HGV is a bimodal distribution fluoroelastomer precompound specifically engineered for extrusion applications, particularly low permeability fuel hose bonding with THV.

Basic Characteristics

Property	Value
Fluorine Content	69.5%
Specific Gravity	1.88
Physical Form	Slab
Color	Off-white
Solubility	Ketones and Esters
Mooney Viscosity ML 1+10@ 121ºC	25

Key Features

Excellent extrusion performance
High loading capacity in formulations
Superior physical properties
Exceptional chemical and penetration resistance

Recommended Processing Procedures

DTR-5925HGV can be compounded using internal mixers or two-roll mills with standard fillers and typical fluoroelastomer formulation ingredients. All dry ingredients should be blended before adding to the rubber solid. Full cooling should be maintained during compounding, and the compound should be cooled rapidly after mixing.

Packaging Information

DTR-5925HGV is packaged with PE film in cartons. Each carton contains 20kg net weight.

Safety and Handling

Store in well-ventilated areas
Strictly prohibit smoking in working areas
Avoid eye contact
Thoroughly wash any contacted skin and clothing after handling

For complete safety and handling guidelines, refer to the product's Material Safety Data Sheet or consult Dowhon personnel.

Typical Properties

Rheological Properties

GOTECH Moving Die Rheometer (GT-M3000A) 100 cpm 0.5 Arc 140℃@ 30min

Property	Value	Test Method
ML, lb.in	2.98	ASTM D6601
MH, lb.in	22.12	ASTM D6601
Ts2, min	1:52	ASTM D6601
T10, min	1:32	ASTM D6601
T90, min	10:28	ASTM D6601

Physical Properties

Press Cure 140℃@30min

Property	Value	Test Method
Tensile Strength, MPa	12.56	ASTM D412
Elongation at Break, %	330	ASTM D412
Hardness, Shore A	77	ASTM D412
Compression Set % (125℃@70h)	27	ASTM D395, method B
Low Temperature Resistance Tr10, ℃	-11	ASTM 1329
