FKM Fluoroelastomer Rubber Precompound 20-60 Mooney Viscosity

MOQ:	20
Price:	10

Detail Information

Product Description

Detail Information

Mooney Viscosity:

20-60

Compression Set:

Thickness:

2mm-8mm

Specification:

445*305*145mm

Production Capacity:

6000mt/Year

F Content:

66%

Specific Gravity:

1.81

Mooney Viscosity ML:

Tensile Strength:

15.9 Mpa

Elongation At Break:

210%

Hardness:

75 Shore A

Compression Set %:

Low Temperature Resistance:

-17ºC

Package Weight:

20kg Net Per Carton

Packing Dimensions:

500kgs/625kgs/700kgs Per Pallet

Highlight:

FKM fluoroelastomer rubber precompound

FKM rubber precompound 20-60 Mooney

fluoroelastomer rubber precompound with warranty

Product Description

Factory Directly OEM Offered FKM Fluoroelastomer Rubber

Company Profile

Fluoroelastomers (FKM) are synthetic rubber materials offering exceptional resistance to heat, chemicals, fuels, oils, solvents, and extreme environments. As part of the fluoropolymer family, they combine high-temperature stability, chemical inertness, and superior mechanical properties.

FKMs consist of a base polymer, typically vinylidene-fluoride (VDF) and hexa-fluoropropylene (HFP), copolymerized with other monomers to achieve specific characteristics. The material's highly saturated fluorinated backbone provides outstanding resistance to heat and chemical degradation.

Manufacturing Capabilities

China's largest FKM manufacturer with 5,500mt output in 2022
2 CNAS approved laboratories
10,000 sqm workshop for smart-wearable devices
100,000 sqm workshop for FKM precompounds and compounds
13 production lines for FKM precompounds and compounds
Over 85% market share in Chinese smart-wearable devices

Product Description: FD-601E

FD-601E is a wide molecular weight distribution fluoroelastomer precompound containing copolymer of hexa-fluoropropylene and vinylidene-fluoride with curatives. Ideal for compression molding products including O-rings, V-rings, and gaskets.

Basic Characteristics

F Content	66%
Specific Gravity	1.81
Physical form	Slab
Color	Off-white
Solubility	Ketones and Esters
Mooney Viscosity ML 1+10@ 121ºC	61

Key Features

Excellent low temperature resistance
Superior chemical resistance
Good mold flow characteristics
Low compression set

Processing Recommendations

FD-601E can be compounded using internal mixers or two-roll mills with standard fillers and ingredients typical for fluoroelastomer formulations. Blend all dry ingredients before adding to the rubbery solid. Maintain full cooling during compounding and cool the compound rapidly after mixing.

Packaging Information

PE film-wrapped cartons containing 20kg net weight each.

Safety & Handling

Store in well-ventilated areas
Strictly prohibit smoking in work areas
Avoid eye contact
Wash thoroughly after skin contact
Consult Material Safety Data Sheet for complete guidelines

Typical Properties

Compound	phr
FD-601E	100
N990	30
MgO-150	3
Ca(OH)2	6
Carnauba Wax	1

Rheological Properties

Property	Value	Test Method
ML, lb.in	2.21	ASTM D6601
MH, lb.in	21.36	ASTM D6601
Ts2, min	1:08	ASTM D6601
T10, min	1:07	ASTM D6601
T90, min	2:16	ASTM D6601

Physical Properties

Property	Value	Test Method
Tensile Strength, Mpa	15.9	ASTM D412
Elongation at Break, %	210	ASTM D412
Hardness, Shore A	75	ASTM D412

Additional Properties

Property	Value	Test Method
Compression set % (200ºC@70h)	18	ASTM D395, method B
Low Temperature Resistance (Tr10, ºC)	-17	ASTM 1329

Packaging & Shipping

20kg/25kg per carton via courier (FedEx, DHL); 500kg/625kg/700kg per pallet for shipping.

Certifications

ISO9001, ISO14001, IATF16949

65 patents held, with 15 invention patents pending. Contributor to 4 National Standards.

Frequently Asked Questions

Q: What's your MOQ?
A: 20-25KG by air, 100KG by sea.

Q: What's your delivery time?
A: 3 working days for stock items, 7-14 working days otherwise.

Q: What's your package?
A: PE film-wrapped cartons (20-25kg each), palletized as 500kg/625kg/700kg units.

Q: How to select the right grade?
A: Contact our sales team for recommendations based on your specific requirements.
